5 HP Air Compressor Electric Motor 3450 RPM 7/8" Shaft 230 V Single Phase
This page is affiliate-supported. Prices and availability can change after the last marketplace refresh.
About this product
This EMZ 5HP single-phase electric motor is designed for air compressor applications, operating at 3450 RPM on 230V or 220V at 60 Hz. It features an ODP (Open Drip-Proof) enclosure and a 7/8" keyed shaft. The motor draws 23 amps at full load and is base-mounted. Its compressor duty rating ensures suitability for demanding air compressor tasks.
Our take
For those needing a high-speed 5HP motor for their air compressor, this EMZ unit with 3450 RPM is a practical choice. The faster speed means quicker recovery for your compressor. The 7/8" shaft is a common size, simplifying replacements. Keep in mind its ODP enclosure, which suggests it's best suited for cleaner, drier environments; protection from moisture and heavy dust is key. The 230V single-phase operation is standard for many workshops. It's a straightforward motor offering the core power and speed for compressor duty.
Pros & Cons
Pros
- 5HP rated load
- 3450 RPM for quick recovery
- 230V / 220V single phase
- 7/8" keyed shaft
- Compressor Duty rated
Cons
- ODP enclosure not for wet/dusty areas
- Non-reversible operation
Specifications
- Brand EMZ
- Rated Load (HP) 5
- Current Type AC
- AC Phase Single Phase
- Nominal Rated Input Voltage 230 V, 220 V
- AC Frequency Rating 60 Hz
Show all 18 specifications
- Base RPM
- 3450
- Enclosure Type
- ODP (Open Drip-Proof)
- Full Load Amps
- 23
- IEC Frame Size
- 56 HZ , 56Y, 182/184Y
- Inverter/Vector Duty Rating
- Compressor Duty
- Mounting Type
- Base-Mounted
- Reversible/Non-Reversible
- Non-Reversible
- Shaft Diameter
- 7/8"
- California Prop 65 Warning
- This Product contains chemicals known to the State of California to cause Cancer, and birth defects or other reproductive harm.
- Shaft Type
- Keyed
- Unit Quantity
- 1
- Unit Type
- Electric Motor
